472M 1KV Ceramic Capacitor 4700pF ±20 Percent Radial Leaded High Voltage

The 472M 1KV Ceramic Capacitor is a high-voltage, radial-leaded capacitor with a capacitance value of 4700 picofarads (4.7nF) and ±20% tolerance. Encased in a flame-retardant epoxy coating, this capacitor offers strong insulation properties and mechanical robustness for high-voltage circuits. With a rated voltage of 1000V, it is well-suited for snubber circuits, power supply filters, CRT circuitry, and other applications requiring reliable high-voltage performance. The ceramic dielectric material provides excellent stability over a wide temperature range and low losses, making it an efficient and durable component for both consumer and industrial electronics.

Key Features:

• Capacitance: 4700pF (4.7nF) with ±20% tolerance (code 472M)
• Rated voltage: 1KV (1000V) suitable for high-voltage filtering and decoupling
• Ceramic dielectric ensures stable performance and low ESR
• Radial leaded through-hole type for secure PCB mounting
• Flame-retardant epoxy resin coating for electrical insulation and protection
• Ideal for power supply circuits, SMPS, CRT, and surge suppression applications

Additional Specifications:

• Tolerance: ±20%
• Capacity: 4700pF
• Capacitor Type: Ceramic
• Rated Voltage: 1000V DC / 250V AC
