Description:
Perform non-contact temperature measurements on transformers, motors, pumps, panels, breakers, compressors, ducts, steam lines, valves, and vents with this infrared thermometer. It features a single laser with a distance to spot ratio of 10:1. Additionally, it's rugged design withstands a 9.8' (3 m) drop.
<h1><strong>Features</strong>:</h1>
⢠Provides a 10:1 Distance to spot ratio
⢠Offers single laser targeting for accurate and repeatable measurements
⢠IP54 rating against dust and moisture
⢠High and low alarms for rapid detection of temperatures outside the limits
⢠Powered by a single, standard AA battery
⢠Withstands a 9.8' (3 m) drop
⢠Small, lightweight form factor to clip comfortably to your tool belt or belt loop, or easily fit in your tool box
⢠A large, backlit display to make data easier to read, even in dark areas
⢠Displays Min/Max/Avg/Dif: the minimum, maximum or average temperature, or the difference between two measurements
<h1><strong>Specifications</strong>:</h1>
⢠Temperature Range -22 to 932°F (-30 to 500°C)
⢠Response Time (95%) <500 ms (95% of reading)
⢠Spectral Response 8 to 14 microns
⢠Emissivity 0.10 to 1.00
⢠Optical Resolution 10:1 (calculated at 90% energy)
⢠Display Resolution 0.2°F (0.1°C)
⢠Repeatability of Readings ±0.8% of reading or <±2°F (1.0°C), whichever is greater
⢠Power AA Battery
⢠Battery Life 10 hours with laser and backlight on
⢠Operating Temperature 32 to 122°F (0 to 50°C)
⢠Storage Temperature -4 to 140°F (-20 to 60°C), without battery
⢠Operating Humidity 10% to 90% RH non-condensing at 86°F (30°C)
⢠Operating Altitude 6561.7' (2000 m) above mean sea level
⢠Storage Altitude 39,370.08' (12,000 m) above mean seal level
⢠Drop Test 9.8' (3 m)
⢠Dimensions 6.88 x 3.34 x 2.95" (175 x 85 x 75 mm)
⢠Weight 0.56 lbs (255 g)
⢠IP Rating IP 54 per IEC 60529
⢠Vibration and Shock IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms
⢠EMC EN 61326-1:2006 EN 61326-2:2006
