WTGAHRS1 10 Axis High Accuracy IMU + GPS Sensor 3
AED 350.00
In stock
Only 7 left
Guarantee safe & secure checkout
Specifications:
Voltage: 3.3V ~ 5V
Current : typical 20mA
Size : 45mm X 62mm X 27mm
Measuring:Attitude angle: 3 axis Acceleration: 3 Axis Angular Velocity: 3 Axis Magnetic 1 axis Atmospheric pressure:height
Range:Acceleration: ± 16g, angular velocity: ± 2000 °/s. Range X (- 180,180) Y(-90,90) Z(-180,180),GPS UBLOX 6M,Atmospheric pressure,height preceision 0.1m
The data output frequency can reach 200Hz
Data Interface: Serial port UART(TTL level).
Baud rate (baud rate 4800-230400 kps. deault 9600kps).
Provide single-chip analytical sample code.
With GPS connectivity. Acceptable in line with NMEA-0183 standard GPS data
| Frequency | N/A |
|---|
