The PIC12C509 is a high-performance 8-bit microcontroller from Microchip Technology, designed for low-power embedded applications. Its compact SMD package allows for easy integration into miniaturized circuits while maintaining robust processing capabilities.
With 1024 x 12-bit EPROM and 41 bytes of RAM, the PIC12C509 provides sufficient memory for small-scale control applications. Operating at 4 MHz, it ensures reliable real-time processing, making it ideal for consumer electronics, industrial automation, and remote monitoring systems.
The microcontroller supports various oscillator configurations, including an internal RC oscillator, external RC, crystal, or ceramic resonators, providing flexibility for diverse applications. Its low power consumption, wide voltage range (2.5V - 5.5V), and power-saving sleep mode make it suitable for battery-operated devices.
Designed for cost-effective and reliable embedded system development, the PIC12C509 offers versatile I/O capabilities, a Watchdog Timer (WDT), and power-efficient operation. Its SMD package allows for compact PCB integration, making it an excellent choice for space-constrained designs.
Key Features :- Compact 8-Bit Microcontroller: Based on a RISC architecture with 33 single-word instructions for high efficiency.
- Wide Voltage Range: Operates from 2.5V to 5.5V, making it suitable for low-power and battery-operated applications.
- 4 MHz Clock Frequency: Provides stable performance for embedded systems.
- On-Chip Memory: Features 1024 x 12-bit EPROM for program storage and 41 bytes of RAM for data handling.
- Flexible Oscillator Configurations: Supports internal 4 MHz RC oscillator, external RC, crystal, or ceramic resonators.
- Power-Saving Features: Includes Sleep Mode and Watchdog Timer for enhanced energy efficiency.
