Description :

- The Sabertooth 2X25 is a versatile and efficient dual motor driver suitable for high powered robots, up to 100lbs in combat or 300lbs for general purpose robotics
-It can supply two DC brushed motors with up to 25A each, with peak currents of 50A per channel achievable for a few seconds
- Overcurrent and thermal protection ensures the driver is protected against accidental stalls or by hooking up too big a motor
- Multiple control options: analog voltage, radio control, serial and packetized serial
- Independent and speed direction operating modes, making it ideal for differential drive (tank style) robots and more
- Onboard DIP switches for easy operating mode setup, no jumpers to lose
- Screw terminal connectors, no soldering required
- The first synchronous regenerative motor driver in its class, regenerative topology allows for recharging of batteries when slowing down or reversing
- Built-in 5V BEC can provide power to a microcontroller or R/C receiver
- Lithium cutoff mode for safe operation with lithium ion and lithium polymer battery packs
- Transistors switched at ultrasonic speeds (32kHz) for silent operation
- Uses 1.3 milliohm MOSFETs in its bridge, rated as a dual 190A motor driver by competitors
- Not recommended to use with cheap AC adapters, use a battery or at least put a battery in parallel with a DC supply.

- Specifications:

•25A continuous, 50A peak per channel.
•6-24V nominal, 30V absolute maximum
•Synchronous regenerative drive
•Ultra-sonic switching frequency
•Thermal and overcurrent protection
•Lithium protection mode
•Input modes: Analog, R/C, simplified serial, packetized serial
•Size: 2.6” x 3.2” x .8”
•65 x 80 x 20 mm (2.6 x 3.1 x 0.8 in)

More Information
Brand DFRobot
GTIN 1,
Memory N/A
I/O Pins N/A
Logic Level N/A
