LM117H ,Adjustable Voltage Regulator, 1.5A Output, TO-3 Package

The LM117H is a high-precision adjustable voltage regulator capable of supplying more than 1.5A of output current. It operates over an adjustable output voltage range from 1.25V to 37V, making it highly versatile for numerous voltage regulation needs. Designed with a wide operating temperature range from -55°C to 150°C, the LM117H ensures reliable operation in extreme environments.

The regulator features a typical line regulation of 0.01%/V and load regulation of 0.1%, providing exceptional voltage stability. With short-circuit protection, thermal overload protection, and safe area compensation, the LM117H is designed to deliver reliable and safe performance. The device is housed in a TO-3 metal can package, which offers efficient heat dissipation, making it ideal for power-intensive applications.

Key Features :

• Package Type: TO-3 metal can package with excellent heat dissipation properties.
• Adjustable Output Voltage: Output voltage range of 1.25V to 37V, customizable with external resistors.
• High Output Current: Provides over 1.5A of output current, suitable for demanding applications.
• Thermal Overload and Short-Circuit Protection: Built-in safety features ensure reliable operation under fault conditions.
• Wide Temperature Range: Operates over a wide temperature range from -55°C to 150°C, making it suitable for extreme environments.
• Low Line and Load Regulation: Ensures output voltage remains stable across varying input voltages and loads.
