IPD70R360P7S, N-Channel 700V CoolMOS™ P7 Power MOSFET, TO-220 Package

The IPD70R360P7S is a high-voltage N-channel power MOSFET from Infineon's CoolMOS™ P7 series, designed for applications requiring efficient power conversion and high-speed switching. With a drain-source voltage rating of 700V and a low on-resistance of 0.36Ω, it minimizes conduction and switching losses, making it suitable for applications such as flyback-based low-power SMPS, including adapters, chargers, lighting, and auxiliary power supplies. The TO-220 package ensures effective heat dissipation, supporting high current handling and enhancing overall system reliability.

• High Voltage Capability: With a drain-source voltage (V_DS) rating of 700V, this MOSFET is ideal for high-voltage applications.
• Low On-Resistance: Features a low R_DS(on) of 0.36Ω, minimizing conduction losses and improving efficiency.
• Fast Switching Performance: Designed for rapid switching, reducing energy loss in high-frequency operations.
• Robust Current Handling: Supports a continuous drain current (I_D) of up to 12.5A, suitable for demanding power applications.
• TO-220 Package: Provides efficient heat dissipation and ease of mounting, enhancing thermal performance.
• Integrated ESD Protection: Built-in electrostatic discharge protection enhances device reliability.
