UDN2982AT,8-Channel Source Driver IC,DIP-18

The UDN2982AT is a high-performance 8-channel source driver IC designed for driving high-current and high-voltage loads. Each channel supports up to 500mA output current, making it ideal for applications such as stepper motors, relays, solenoids, lamps, and LED arrays.

This device features integrated transient suppression diodes and input current-limiting resistors to ensure reliable operation in harsh environments. With a maximum output voltage of 50V and compatibility with TTL, DTL, PMOS, and CMOS logic inputs, the UDN2982AT provides exceptional versatility for various power-driving tasks.

Packaged in a DIP-18 form factor, the UDN2982AT is optimized for ease of integration in PCB layouts. Its robust design and high efficiency make it a preferred choice for industrial, automotive, and consumer electronics applications requiring reliable high-side switching capabilities.

• 8-Channel High-Side Drivers: Supports up to 8 output channels for driving relays, lamps, solenoids, or LED arrays.
• High Current Capability: Delivers up to 500mA per channel for efficient high-power load driving.
• Wide Input Voltage Range: Compatible with TTL, DTL, PMOS, and CMOS logic inputs.
• Built-In Protections: Includes transient suppression diodes and input current-limiting resistors for robust operation.
• Compact DIP-18 Package: Easy to integrate into designs for industrial and consumer applications.
• High Voltage Tolerance: Handles output voltages up to 50V, suitable for demanding power requirements.
