PIC16F76-1.SP, 8-bit Microcontroller, 8192 Words Flash, 368 Bytes RAM

The PIC16F76-1.SP is a high-performance 8-bit microcontroller featuring 8K words of Flash Program Memory, 368 bytes of RAM, and 22 I/O pins. Designed with RISC architecture, it efficiently executes instructions, making it ideal for embedded systems, automation, and industrial control applications. The device includes three timers, CCP (Capture/Compare/PWM) modules, an 8-bit ADC, and communication interfaces such as USART and I2C/SPI, ensuring seamless integration into complex systems.

The power management features, including Sleep Mode, Watchdog Timer (WDT), and Brown-out Reset (BOR), enhance its reliability in power-sensitive applications. With multiple operating modes, the PIC16F76-1.SP is an excellent choice for engineers looking to design efficient and powerful embedded solutions.

• High-Performance RISC CPU – Features only 35 single-word instructions and operates at speeds up to 20 MHz.
• Flash Program Memory – Equipped with 8K words of Flash for program storage, allowing flexible development.
• Robust Peripheral Set – Includes CCP modules, timers (8-bit & 16-bit), USART, and I2C/SPI communication for diverse applications.
• Integrated Analog Features – Features an 8-bit, up to 8-channel ADC for precise signal processing.
• Flexible I/O Configuration – Provides 22 general-purpose I/O pins, configurable for various digital and analog functions.
• Low Power Operation – Supports Sleep Mode, Watchdog Timer, and Brown-out Reset (BOR) for energy-efficient applications.
