AM27S13APC, 4K-bit Bipolar PROM, 55ns Access Time, 5V, DIP-24

The AM27S13APC is a 4K-bit (512 x 8-bit) Bipolar Programmable Read-Only Memory (PROM) designed for high-speed data storage applications. Utilizing advanced Schottky TTL technology, this PROM delivers an ultra-fast access time of 55ns, making it suitable for use in control logic, embedded systems, and industrial computing.

As a one-time programmable (OTP) memory, the AM27S13APC allows users to permanently store firmware, configuration data, or control sequences. Once programmed, the data remains non-volatile, ensuring long-term reliability without the need for power backup.

The device operates within a standard 5V power supply (4.5V - 5.5V) and is fully compatible with TTL logic levels, simplifying integration into existing circuits. The DIP-24 package enables easy PCB mounting, making it an ideal choice for legacy computing, robotics, control systems, and industrial automation.

• 4K-bit Bipolar PROM: Organized as 512 x 8-bit, providing permanent non-volatile storage.
• Fast Access Time: Offers a 55ns access time, ensuring quick data retrieval for high-speed applications.
• Standard 5V Power Supply: Operates within 4.5V to 5.5V, making it compatible with standard TTL logic systems.
• Permanent Data Storage: One-time programmable (OTP) memory, making it ideal for firmware and control logic applications.
• High-Speed Operation: Designed with Schottky technology to optimize speed and reliability in data access.
• Industry-Standard DIP-24 Package: Easily integrates into legacy and industrial systems.
