Product Features

◆ Using the technology of lithium iron phosphate cell,
superior safety, thousands of cycles, 100%DOD,
under normal conditions.
◆ Built-in automatic protection for over-charge, over
discharge, over current and over temperature.
◆ Free of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a
comparable lead acid battery.
◆ Replacement for lead-acid battery.
◆ Wider temperature range:-20°C~60°C.
◆ Support for Series application expansion

Electrical Characteristics

Nominal Voltage 12.8V
Nominal Capacity 200Ah@0.2C
Min. Capacity 200Ah@0.2C
Nominal Energy 2560Wh
Internal Resistance ≤18mΩ
Cycle Life 2000 Cycles @40A Charging/Discharging ,Until 70% Capacity
Self Discharge ≤3.5% per month at 25°C
