Teensy USB Board, Version 4.0, With Pins Soldered

<h1><strong>Description:&nbsp;</strong></h1> <p>&nbsp;</p> <p>The Teensy 4.0 is the newest offering from the Teensy line, bringing the most powerful microcontroller and advanced peripherals in a compact 1.4 by 0.7-inch package. It boasts an ARM Cortex-M7 processor running at 600MHz and is equipped with the NXP iMXRT1062 chip, the fastest microcontroller currently available. Despite its power, the Teensy 4.0 maintains the same form factor as the Teensy 3.2 and is compatible with most of its pin functions.</p> <p>&nbsp;</p> <h1><strong>Features</strong>:</h1> <ul> <li>USB Host: 2 SMT Pads</li> <li>SDIO (4 bit data): 8 SMT Pads</li> <li>PWM Pins: 31</li> <li>Analog Inputs: 14 </li> <li>Serial Ports: 7 </li> <li>Flash Memory: 2 Mbyte </li> <li>QSPI Memory: Program Memory</li> <li>Breadboard I/O: 24 </li> <li>Bottom SMT Pads: 16</li> <li>SD Card Signals: 0</li> <li>Total I/O Pins: 40</li> </ul> <p>&nbsp;</p> <h1><strong>Specifications</strong>:</h1> <ul> <li>ARM Cortex-M7 at 600 MHz</li> <li>Float point math unit, 64 &amp; 32 bits</li> <li>1984K Flash, 1024K RAM (512K tightly coupled), 1K EEPROM (emulated)</li> <li>USB device 480 Mbit/sec &amp; USB host 480 Mbit/sec</li> <li>40 digital input/output pins, 31 PWM output pins</li> <li>14 analog input pins</li> <li>7 serial, 3 SPI, 3 I2C ports</li> <li>2 I2S/TDM and 1 S/PDIF digital audio port</li> <li>3 CAN Bus (1 with CAN FD)</li> <li>32 general-purpose DMA channels</li> <li>Cryptographic Acceleration &amp; Random Number Generator</li> <li>RTC for date/time</li> <li>Programmable FlexIO</li> <li>Pixel Processing Pipeline</li> <li>Peripheral cross triggering</li> <li>Power On/Off management</li> </ul> <p>&nbsp;</p>
