TIC206D ,Silicon Triac 400V 4A TO-220 Package

The TIC206D is a silicon triac that operates in four quadrants, designed for controlling AC loads. It is constructed with a glass-passivated wafer, offering stability and high performance. This triac can handle up to 4A RMS on-state current and a repetitive peak off-state voltage of 400V.

With a peak gate trigger current as low as 5mA, this triac is suitable for sensitive gate triggering. The TIC206D can be used in a wide range of applications, including motor speed controls, lighting dimmers, static relays, and phase control operations. The TO-220 package offers robust mechanical design for easy mounting.

Key Features:

• Sensitive Gate Triggering: Low peak gate trigger current of 5mA for easy control.
• High Surge Capability: Capable of handling up to 25A non-repetitive surge current.
• Voltage Rating: Withstands a repetitive peak off-state voltage of 400V.
• Robust Package: Comes in a TO-220 package with electrically isolated mounting for improved thermal dissipation.
• RMS On-State Current: Handles up to 4A RMS current for consistent performance in AC switching applications.
• Wide Operating Temperature Range: Functions within a temperature range of -40°C to +110°C, ensuring reliable performance in various environments.
