24V Inverter/Battery Charger with double AC outputs, adaptive charge technology, and high-speed AC transfer switch. It features a four-stage adaptive charger, power control, and power assist. It is compatible with Lithium-ion batteries and can be installed in parallel up to 6 units. It has a maximum AC input current of 16A - 230V (3,6Kw). Model: 24/3000/70-16 with input voltage range of 19-33V, a continuous output power of 3000VA, and a charge current of 70A 4A. It weighs 18kg (39.7lbs) and measures 362x258x218 mm (14.2x10.1x8.6 inches).

Features:

True sine wave inverter
Adaptive charge technology
High-speed AC transfer switch
Compact enclosure
Compatible with Lithium-ion batteries
Double AC outputs
No-break function for main output
Active second output for AC sources
Parallel operation up to 6 units
Three-phase configuration for up to 6 sets of three units
Power Control to avoid overload
Power Assist to boost energy availability
Four stage adaptive charger with dual battery charging
DIP switch setting procedure for system configuration
VE.Net panel or Digital Multi Control remote control for setting modifications

Specifications:

Model: 24/3000/70-16
Input Voltage range: 19 – 33V
Continuous output power VA: 3000
Charge current: 70A 4 A
Max AC input current: 16A - 230V (3,6Kw)
Weight: 18 kg (39.7 lbs)
Size: 362x258x218 mm (14.2x10.1x8.6 inches)
