HY-CS6714D Digital Ammonia Nitrogen Sensor

• Power Supply – 9-36 VDC
• Output – RS485 Modbus RTU
• Measurement Method – Ion Electrode Method
• Shell Material – PP
• Shape – Diameter 30mm * Lenght 160mm
• Waterproof Grade – IP68
• Measurement Range – 0-100 mg/L, Expandable
• Measurement Accuracy – Reading ±2.5 %
• Pressure Range – ≤ 0.3 MPa
• Temperature Compensation – NTC10K
• Temperature Range – 0 -50Ëš
• Calibration – Standard Solution Calibration, water sample calibration
• Connection Mode – 4-core cable
• Cable Length – 10m Cable provides as standard, Extended to 100 meters
• Measuring Thread – NPT 3/4″
• Scope of Application – General Application, river, lake, drinking water, environmental protection, etc.
