Description :

-Dual channel DC motor driver with small size of 1.97”×1.97”×0.49”
-Each channel can drive a motor simultaneously and has an indicator to show the rotation direction
-Motor voltage range: 6.5V to 37V
-Continuous current output: 12A per channel, max power of 290W
-Momentary peak current: 70A, lasting for 100ms
-Highly optimized for PWM input with a minimum pulse width of 2us
-Built-in over-voltage, under-voltage, and overheat protection
-On-board STATE indicator to show protection state: ON->Work properly; Flashing quickly->Over-voltage; -Flashing slowly->Under-voltage; Double flashing->Overheat
-Can be used with Arduino controller for easy motor control
-Suitable for various applications such as automatic robots, mechatronics, equipment manufacturing, scientific production, electronics competition.

-Specifications:

•Motor Channel: 2
•Signal Control Voltage: 3V-5V compatible
•Input Voltage: 6.5-37V DC
•Peak Current: 70A(100ms), the current will be limited as the temperature increases.
•Continuous Current: each channel can output 12A current continuously
•Operating Temperature: -25-85℃
•Overheat Temperature: 85℃-95℃
•Over-voltage: 37.5V
•Under-voltage: 6.3V
•Dimension: 50mm×50mmx12.5mm/1.97”×1.97”×0.49”
•Built-in over-voltage, under-voltage and overheat protection circuit, onboard STATE indicator to show the present work state.
