DC Fans dc axial fan, 80 mm square, 15 mm, 12 Vdc, ball, 3000 RPM, 34.85 CFM, TS CFM-8015BF-130-301-20

SKU
CTFx0138
Brand
Out Of Stock
Add to Wish List

Notify me when this product is available:

Guarantee safe & secure checkout

Fan Tubeaxial 12VDC Square - 80mm L x 80mm H Ball 34.9 CFM (0.977m³/min) 3 Wire Leads


Specifications:


Voltage - Rated: 12VDC
Size / Dimension: Square - 80mm L x 80mm H
Width: 15.40mm
Air Flow: 34.9 CFM (0.977m³/min)
Static Pressure: 0.100 in H2O (24.9 Pa)
Bearing Type: Ball
Fan Type: Tubeaxial
Features: Auto Restart, Speed Sensor (Tach)
Noise: 30.1dB(A)
Power (Watts): 3.12 W
RPM: 3000 RPM
Termination: 3 Wire Leads
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Approval Agency: CE, cURus, TUV
Current Rating (Amps): 0.260A
Voltage Range: 10.8 ~ 13.2VDC
Material - Frame: Polybutylene Terephthalate (PBT)
Material - Blade: Polybutylene Terephthalate (PBT)



More Information
Brand CUI Devices
